Product Details
Automatic
Automatic
Color
Blue
Voltage
220V
Type
Belt Dryer
Country of Origin
India
Band Dryer with SS-304 Band and Auto Alignment of Board
Continuous conveyor Band Dryer is Ideal for drying thin Face Veneer, Sliced / Peeled Decorative Veneers, PF Resin Impregnated Core Veneers, Bamboo Mat/ Curtain etc. The machine has stainless steel Bands or
Conveyors for rust-free operation. Each deck has a set of pressing Band to keep the dried material in portion and prevent wear and tear. Double set of Jet Boxes provide uniform drying all along the length of the Dryer.
The Dryer has extended feeding section to enable proper arrangement of the materials during feeding. The Dryer is supplied with specially designed Alloy Fan and Dyno Drive for variable feed speeds and Band
Tensioning with Auto Alignment System along with separate desk Feeding & Discharge Conveyors. Standard Models of Band Dryers are available in 4 section 3 deck, 5 section 3 decks, 8 Section 3 deck, 10 Section 3 deck. Technical Data – 10’ / 2750mm Standard Band Width MESH / BAND Dryer for Thin Veneer
Technical data
| Mesh Dryer | Steam Kg / Hrs |
Thermic Fluid K Cal / Hrs. |
Power HP / KW | CBM |
| 6 Section 3 deck | 1200 | 5,00,000 | 45 / 33.5 | 40 |
| 7 Section 3 deck | 1400 | 6,00,000 | 50 / 37.3 | 50 |
| 8 Section 3 deck | 1600 | 7,00,000 | 55 / 41.0 | 65 |
| 10 Section 3 deck | 1800 | 8,00,000 | 70 / 52.2 |
100 |
